Hydraulic piston fillers Mod. Economica 20L 30L 50L
TECHNICAL SPECIFICATIONS
- Made of stainless steel.
- Removable cylinder for its cleaning.
- Stainless steel and plastic inner piston.
- Plastic lid fixed by four columns.
- Pressure regulator with manometer.
- Flow regulator to ensure constant speed.
- Knee with fixation.
- Separate cooled oil tank, with level indicator.
- Can be placed horizontally resting on the back.
- Removable superior part for keeping it under one table.
- 24-volt controls.
- Powerful equipment to ensure efficient operation with any kind of product.
- Supported on two wheels and two fixed feet.
- Hydraulic installation with flexible high-pressure hoses.
- Automatic cylinder decompression.
- Hydraulic cylinder with stainless steel rod and nut.
- Ø15, Ø20 and Ø30 mm tubes.
- Oil incorporated.
- Very easy operating.
- Minimum maintenance.
Mod. ECONOMICA 20L (Motor 750 watts, machine dimensions: 501 x 371 x 1,200 mm, net weight: 97kg.)
Mod. ECONOMICA 30L (Motor 1,000 watts, machine dimensions: 541 x 406 x 1,207 mm, net weight: 133kg.)
Mod. ECONOMICA 50L (Motor 1,470 watts, machine dimensions: 591 x 476 x 1,220 mm, net weight: 205kg.)
QUALITY AT MINIMUM PRICE
